Container with publish mode ingress not starting

Good day everyone,

I’m new to docker and docker swarm and i’m stuck with a really strange issue.
When creating a service with a simple tftp container for some reason it’s impossible to get it working with an ingress overlay network, host mode is totally fine and works.

OS: Ubuntu 22.04.1 LTS (GNU/Linux 5.15.0-1013-raspi aarch64)

Docker Version:

Client: Docker Engine - Community
 Version:           20.10.17
 API version:       1.41
 Go version:        go1.17.11
 Git commit:        100c701
 Built:             Mon Jun  6 23:02:17 2022
 OS/Arch:           linux/arm64
 Context:           default
 Experimental:      true

Server: Docker Engine - Community
 Engine:
  Version:          20.10.17
  API version:      1.41 (minimum version 1.12)
  Go version:       go1.17.11
  Git commit:       a89b842
  Built:            Mon Jun  6 23:00:41 2022
  OS/Arch:          linux/arm64
  Experimental:     false
 containerd:
  Version:          1.6.6
  GitCommit:        10c12954828e7c7c9b6e0ea9b0c02b01407d3ae1
 runc:
  Version:          1.1.2
  GitCommit:        v1.1.2-0-ga916309
 docker-init:
  Version:          0.19.0
  GitCommit:        de40ad0

It’s running on a two node swarm with a raspberry pi 3b+ and 4.

This does start and work

docker service create \
  --mode global \
  --publish mode=host,target=69,published=69,protocol=udp \
  --name=tftp \
  -e TZ="Europe/Berlin" \
  -e CREATE=1 \
3x3cut0r/tftpd-hpa:latest

If you change publish mode to ingress the containers are stuck in “new” and will never start, waited hours…

docker service create \
  --mode global \
  --publish mode=ingress,target=69,published=69,protocol=udp \
  --name=tftphost \
  -e TZ="Europe/Berlin" \
  -e CREATE=1 \
3x3cut0r/tftpd-hpa:latest

Is that a limitation of any kind i’m not aware of ? Any ideas ?

Your last command works like a charme on Ubuntu 20.04 with the same docker-ce version on x86_64.
Could be kernel differences… or be a bug in the docker-ce arm version …

You could check if your kernel supports all required modules:

curl https://raw.githubusercontent.com/docker/docker/master/contrib/check-config.sh | bash

Modules are looking fine i think only optional stuff missing.

Generally Necessary:
- cgroup hierarchy: cgroupv2
  Controllers:
  - cpu: available
  - cpuset: available
  - io: available
  - memory: available
  - pids: available
- apparmor: enabled and tools installed
- CONFIG_NAMESPACES: enabled
- CONFIG_NET_NS: enabled
- CONFIG_PID_NS: enabled
- CONFIG_IPC_NS: enabled
- CONFIG_UTS_NS: enabled
- CONFIG_CGROUPS: enabled
- CONFIG_CGROUP_CPUACCT: enabled
- CONFIG_CGROUP_DEVICE: enabled
- CONFIG_CGROUP_FREEZER: enabled
- CONFIG_CGROUP_SCHED: enabled
- CONFIG_CPUSETS: enabled
- CONFIG_MEMCG: enabled
- CONFIG_KEYS: enabled
- CONFIG_VETH: enabled (as module)
- CONFIG_BRIDGE: enabled (as module)
- CONFIG_BRIDGE_NETFILTER: enabled (as module)
- CONFIG_IP_NF_FILTER: enabled (as module)
- CONFIG_IP_NF_TARGET_MASQUERADE: enabled (as module)
- CONFIG_NETFILTER_XT_MATCH_ADDRTYPE: enabled (as module)
- CONFIG_NETFILTER_XT_MATCH_CONNTRACK: enabled (as module)
- CONFIG_NETFILTER_XT_MATCH_IPVS: enabled (as module)
- CONFIG_NETFILTER_XT_MARK: enabled (as module)
- CONFIG_IP_NF_NAT: enabled (as module)
- CONFIG_NF_NAT: enabled (as module)
- CONFIG_POSIX_MQUEUE: enabled
- CONFIG_CGROUP_BPF: enabled

Optional Features:
- CONFIG_USER_NS: enabled
- CONFIG_SECCOMP: enabled
- CONFIG_SECCOMP_FILTER: enabled
- CONFIG_CGROUP_PIDS: enabled
- CONFIG_MEMCG_SWAP: enabled
    (cgroup swap accounting is currently enabled)
- CONFIG_BLK_CGROUP: enabled
- CONFIG_BLK_DEV_THROTTLING: enabled
- CONFIG_CGROUP_PERF: enabled
- CONFIG_CGROUP_HUGETLB: enabled
- CONFIG_NET_CLS_CGROUP: enabled (as module)
- CONFIG_CGROUP_NET_PRIO: enabled
- CONFIG_CFS_BANDWIDTH: enabled
- CONFIG_FAIR_GROUP_SCHED: enabled
- CONFIG_RT_GROUP_SCHED: missing
- CONFIG_IP_NF_TARGET_REDIRECT: enabled (as module)
- CONFIG_IP_VS: enabled (as module)
- CONFIG_IP_VS_NFCT: enabled
- CONFIG_IP_VS_PROTO_TCP: enabled
- CONFIG_IP_VS_PROTO_UDP: enabled
- CONFIG_IP_VS_RR: enabled (as module)
- CONFIG_SECURITY_SELINUX: enabled
- CONFIG_SECURITY_APPARMOR: enabled
- CONFIG_EXT4_FS: enabled
- CONFIG_EXT4_FS_POSIX_ACL: enabled
- CONFIG_EXT4_FS_SECURITY: enabled
- Network Drivers:
  - "overlay":
    - CONFIG_VXLAN: enabled (as module)
    - CONFIG_BRIDGE_VLAN_FILTERING: enabled
      Optional (for encrypted networks):
      - CONFIG_CRYPTO: enabled
      - CONFIG_CRYPTO_AEAD: enabled
      - CONFIG_CRYPTO_GCM: enabled
      - CONFIG_CRYPTO_SEQIV: enabled
      - CONFIG_CRYPTO_GHASH: enabled
      - CONFIG_XFRM: enabled
      - CONFIG_XFRM_USER: enabled (as module)
      - CONFIG_XFRM_ALGO: enabled (as module)
      - CONFIG_INET_ESP: enabled (as module)
  - "ipvlan":
    - CONFIG_IPVLAN: enabled (as module)
  - "macvlan":
    - CONFIG_MACVLAN: enabled (as module)
    - CONFIG_DUMMY: enabled (as module)
  - "ftp,tftp client in container":
    - CONFIG_NF_NAT_FTP: enabled (as module)
    - CONFIG_NF_CONNTRACK_FTP: enabled (as module)
    - CONFIG_NF_NAT_TFTP: enabled (as module)
    - CONFIG_NF_CONNTRACK_TFTP: enabled (as module)
- Storage Drivers:
  - "aufs":
    - CONFIG_AUFS_FS: missing
  - "btrfs":
    - CONFIG_BTRFS_FS: enabled (as module)
    - CONFIG_BTRFS_FS_POSIX_ACL: enabled
  - "devicemapper":
    - CONFIG_BLK_DEV_DM: enabled
    - CONFIG_DM_THIN_PROVISIONING: enabled (as module)
  - "overlay":
    - CONFIG_OVERLAY_FS: enabled (as module)
  - "zfs":
    - /dev/zfs: present
    - zfs command: missing
    - zpool command: missing

Limits:
- /proc/sys/kernel/keys/root_maxkeys: 1000000


Yeah i start to believe i have found a bug that i have wasted now hours on thinking it was my mistake somewhere.

Thanks for confirming that it theoretically should work :smiley:

1 Like

It indeed looks like bug! Now the only action left is to raise an issue here:

1 Like

Hey there, I’m bumping into the same issue on docker 23.0.1 on rpi with ubuntu 22.04 64bit and wondering if you managed to figure out what this issue is and whether you found a way around it, or filed a bug.

Thank you very much in advance!
